Battleline

May 11, 2005, 11:26 AM

Hello, I'm new to this forum, so I apologize for starting out by asking for help.

I'm having a problem trying to get my custom vertex shader in DirectX 8 to recognize that I'm trying to send it transformed vertices for the screen sized quad I'm trying to render. Instead, the quad appears to be picking up the world/view transformation from the last object I rendered in my scene.

Here's a screen shot:
http://www.epochstar.com/VS1.jpg

Notice my quad is being rendered in the upper left corner of the screen. I'm trying to get it to take up the entire screen. Is there something I can do in my vertex shader to make it recognize I'm dealing with pre-transformed vertices? Is there anything else I can do to get my quad to render full screen?

Thanks


bignobody

May 11, 2005, 12:35 PM

While the screenshot helps illustrate the problem, without some relevant code posted things become a guessing game. So here's my first guess ;)

In your FVF declaration are you using D3DFVF_XYZ instead of D3DFVF_XYZRHW?


Battleline

May 11, 2005, 12:36 PM



bignobody wrote: While the screenshot helps illustrate the problem, without some relevant code posted things become a guessing game. So here's my first guess ;) In your FVF declaration are you using D3DFVF_XYZ instead of D3DFVF_XYZRHW?


No, I'm using RHW. I'll post some code a little later. I'm not in a place where I can get to it right now.

Thanks


Steven Hansen

May 11, 2005, 01:25 PM

If you are using a vertex shader, then you have to map screen coordinates to the viewport clipping volume inside the shader. From DxDocs, "Microsoft Direct3D assumes that the viewport clipping volume ranges from -1.0 to 1.0 in X, and from 1.0 to -1.0 in Y."

I've run across and solved this problem numerous times. Post more specifics and we'll help you out further if you need it.


arex

May 25, 2005, 05:32 AM

Remember that you must set the matrices before (for shader) the object and need to also recalculate them again (if there is some chances been made).
